Shacman 4/5 Axle Oil Tanker Semi-Trailer is a heavy-duty vehicle designed for the transportation of oil and other liquid products. It features a robust construction, ensuring safe and efficient delivery of goods. The Shacman 4/5 Axle Oil Tanker Semi-Trailer is equipped with a large capacity tank, capable of carrying a significant amount of oil or other liquids.
The semi-trailer is built with a 4/5 axle configuration, providing excellent stability and load-bearing capacity. This allows it to handle heavy loads without compromising on safety or performance. The trailer also comes with advanced braking systems, ensuring smooth and controlled stops, even when transporting large volumes of oil.
In addition, the Shacman 4/5 Axle Oil Tanker Semi-Trailer is designed with user-friendly features such as easy access to the tank for maintenance and cleaning purposes. The trailer also complies with various international safety and environmental standards, making it an ideal choice for businesses looking to transport oil and other hazardous materials in an environmentally responsible manner.
| Shacman 4/5 Axle Oil Tanker Semi-Trailer Specification | |
| Product Type | Oil Tanker Semi-Trailer |
| Main Chassis Material | Strengthened “I” section centre members are welded automatically by submerged welding machine. They are welded between 140/14-16 mm and main beam is 5-6 mm , Octopus System for Chassis for tough African road conditions |
| Tank body | Volume：23,000-120,000 cbm；Capacity28-150 tons；Tank body material 5.5mm， carbon steel/aluminum alloy/stainless steel End plate 6mm carbon steel Manhole cover diameter 500 mm 2 pieces, material aluminium |
| Semi Trailer Axle Specification | |
| Number of Axles | 2-3-4-5 axles |
| Axle Brake Type | Drum brake type (Optional disc brake type) |
| Each Axles Capacity | 13 tons capacity (Optional up to 20 tons) |
| Each Sequence Twin/Single Wheel | Single wheel (Depends on tire dimension) |
| Number of Steered Axles and Position | Optional other options |
| Semi Trailer Suspension Equipment | |
| Suspension Type | Suspensions : Air Suspension, Front Axle Liftable (Optional) |
| Trailer Tires & Rims Specifications | |
| Tire Dimensions | 12R22.5 (Optional any compatible size) |
| Total Tire & Rim Unit | With 385/65 R 22.5 option, |
| Other Compatible Tire Sizes | 12.00R20 (Double tire size optional) |
| Semi Trailer Brake System | |
| Air Line | Standard Dual circuit brake hardware |
| Brake System | EBS (Optional 4S/3M or 4S/4M) WABCO or KNORR brand (Optional only ABS System) |
| Brake Slack Adjusters | Automatic type |
| Semi Trailer Electrical Equipment | |
| Electrical Input Voltage | Standard 24V |
| Socket Type | Standard 7 (optional 15 pins) NATO type or any type distribution cable |
| Ex-Proof Compatibility | Available as optional |
| Lighting Functions | Brake, signal, stop, reversing and fog lights, side lights, reversing lights, license plate lights |
| Other Standard Equipment | |
| King Pin | 50#/90# |
| Landing Legs | Dynamic 24 ton, static 50 tons capacity, one side controlled |
| Lockable Cabinets | 1-2 units |
| Spare Tire Holder | 1-2 units |
| Operate the shining vest | 1-2 units |
| Water Tank | 1 water tank with soap dispenser |
| Mudguards | 3 sets of half mudguard |
