FAST gearbox: Large center distance 10/12 gearbox with unique twin shaft structure. The gearbox features with advanced reliable low speed ratio and high grade ability, efficient transportation, and lower fuel consumption; especially suitable for long distance transportation and tough working condition.
Hande axle: Steyr drive axle, leading single reduction axle, heavy duty off-road military truck axle technology from German MAN, FAG low-drag maintenance-free bearing technology, and 500,000 km maintenance-free. It won’t break down after working for 1.318 million times impulsive axial loads, lower fuel consumption and bearing capacity, economic speed is faster and fuel consumption lower.
WEICHAI power: High horsepower engine combined with AVL and BOSCH for golden power. Engines are customized for SHACMAN vehicles with intelligent fuel saving system that can automatically adjust according to changing vehicle weight. Strong power with large output torque, lower engine speed at maximum torque, best power and explosive force in the industry.Cummins power: Cummins and
SHACMAN Group develop the ISM series fully electronically controlled engines with intelligent controls together with excellent power. Five key systems take the leading position in the world,the horsepower covers 385-440PS, with heavy torque,fuel economic, good product adaptability, strong power,perfect handling and low noise as well as first class reliability and durability,free of maintenance for 1 million kilometers.
| Representative Vehicle Model | SX11858J571 | |
| Cabin | L3000 cabin with one berth (sleeper), with Air-conditioner (A/C), up/down and front/back adjustable steering wheel, safety belt, exterior sun visor etc. | |
| Engine | Model | WEICHAI, WP6.210E32, 210HP, Euro II |
| Type | 6 cylinder in line, 4 stroke direct injection diesel engine, water cooling, Intercooler Turbocharged. | |
| Clutch | Hydraulic control air assisted. | |
| Transmission | FAST brand, 8JS85TM, 8 forwarder & 2 reserve, manual.Main and auxiliary transmission structure, main transmission with double counter shaft , auxiliary transmission with planetary reduction. | |
| Steering System | ZF technology, power steering with hydraulic system. | |
| Front axle | 4800kg, disc brake | |
| Rear axle | 10000kg, MAN single-stage reduction axle | |
| Braking System | Service brake: dual-circuit air pressure brake;Parking brake (emergency brake): spring storage energy without air.Auxiliary brake: Engine exhaust brake. | |
| Electrical System | Voltage: 24VGenerator: 1540WStarter: 7.5 kWBattery: 12V/165Ah, 2 pieces.Cigar-lighter, horn, headlamps, fog lights, brake lights, indicator and reverse light. | |
| Tire | 10.00R20, steel radial tires, plus one spare tire (totally 7 units) | |
| Tank Volume (L) | 200L | |
| Kerb Weight (kg) | 6000 | |
| Gross Weight (kg) | 19000 | |
| Maximum Speed (km/h) | 90 | |
| Cargo box dimension (mm) | 7800X2300X800 | |
| Overall dimension (mm) | 9340X2550X3000 | |
