Shacman X3000 12 Wheeler Dump Truck

Shacman X3000 12 Wheeler Dump Truck

Model – SX33186V306C
Engine – WP12.430E201
Series – X3000
Power – 430hp
Tank Volume (L) – 360L
Displacement – 10.8L
Rated output – 309kW
DESCRIPTION
Shacman X3000 12 Wheeler Dump Truck Introduce

Shacman X3000 12 Wheeler Dump Truck is equipped with an 8X4 drive type, which provides excellent traction and stability on any terrain. With a payload capacity of 11t GVW and 90t GCW, it is capable of carrying a lot of cargo. The frame of the Shacman X3000 12 Wheeler Dump Truck is 850×320(8+7)mm, providing robust support to the vehicle structure.

Shacman X3000 12 Wheeler Dump Truck is light in weight and strong in carrying capacity, and is mainly used for the standard transportation of toll roads for medium and short distances such as coal resources, sand and gravel and other infrastructure materials. Our Shacman X3000 12 Wheeler Dump Truck is suitable for standard coal transportation in areas with strict weight charges.

Shacman X3000 12 Wheeler Dump Truck-3
Shacman X3000 12 Wheeler Dump Truck

Shacman X3000 12 Wheeler Dump Truck is made of high-strength steel plate, which makes the vehicle’s center of gravity lower, lighter weight, and stronger carrying capacity. This Shacman X3000 12 Wheeler Dump Truck has been carefully designed and manufactured by us, with strong carrying capacity, long service life, easy procurement of accessories, and easy maintenance. Shacman X3000 12 Wheeler Dump Truck is one of the best choices for customers.

shacmantruks video-2
CHARACTERISTICS
Truck Name Shacman X3000 12 Wheeler Dump Truck
Edition Super edition
Vehicle model SX33186V306C
Drive 8X4
Wheelbase (mm) 1800+2975+1400
Suspension Multi leaf springs
Engine WP12.430E201
Horsepower 430HP
Emission standard Euro Ⅱ
Displacement 10.8L
Rated output 309kW
Max.torque 2000N.m
Transmission 12JSD200TA-B-QH50+FHB400
Clutch 430
Frame 850×300(8+7+8)
Front axle MAN 9.5T
Rear axle 16T MAN two-stage widened bridge 4.769
Tire 12.00R24
Fuel Diesel
Fuel tank 360L (Aluminum shell)
Battery 180Ah
Inner dimension of loading space(mm) 7300X2300X1500
Material thickness of loading(mm) Bottom12,Side10
Lifting mode Multistage front lifting hydraulic system
Cab ◆Shacman X3000 mid-length flat-top cab does not have a roof shroud
◆Automated air conditioning
◆Four-point hydraulic mounting
◆Air cushioned drivers seat
◆Water tank protection grid
◆Electric window
Optional 315/80R22.5
Shacman X3000 12 Wheeler Dump Truck-3
Shacman X3000 12 Wheeler Dump Truck-2
Shacman X3000 12 Wheeler Dump Truck-1
shacman x3000 dump truck-9
shacman x3000 dump truck-11
shacman x3000 dump truck-5
