Shacman X9 4X2 Tipper Light Truck

Shacman X9 4X2 Tipper Light Truck

Model – SX3163E2Y13B3620

Driving Type – 4×2

Type of vehicle – Light Truck

Series – X9

GCW – ≤16T

Tank Volume (L) – 130

Wheelbases（mm） – 3600

WhatAPp message

DESCRIPTION

Shacman X9 4X2 Tipper Light Truck

The Shacman X9 4X2 Tipper Light Truck is a new model of dump truck. It is mainly used for transporting sand and gravel, earthwork, bricks, white ash, putty powder, cement, steel, construction waste, domestic waste, wood, muck, etc. It is a good helper for carrying self-employed individuals, engineering contractors and municipal sanitation departments

Shacman X9 4X2 Tipper Light Truck Versatile Customization Options

Diverse Configuration Flexibility The Shacman X9 4X2 tipper light truck offers extensive customization to meet specific operational needs. Customers can choose from various drive types (4×2, 4×4, etc.), left or right-hand drive, and engine power options.
Tailored Loading Capacities It supports loading capacities ranging from 1 ton to 40 ton, with the 4X2 model typically handling 5-6 ton loads, suitable for light to medium-duty transportation.
Multiple Body Types Available body configurations include low fence, van, stake, and wing span designs, along with optional rear lifting platforms for enhanced cargo handling.

Shacman X9 4X2 Tipper Light Truck Practical Performance Features

Efficient Power System Equipped with a YN4102QBZL engine delivering 115hp and Euro II emission standard compliance, paired with a 6-speed manual transmission for reliable highway performance.
Optimized Dimensions The truck features a compact cargo body size (standard 42002100600mm, customizable) and overall dimensions of 5950x2200x2600mm, ensuring maneuverability in urban and rural environments.
Durable Chassis Configuration Front axle (2.5ton) and rear axle (5ton) setup, combined with 7.50R16 tires (6+1), provides stable load-bearing capacity for tipper operations.

CHARACTERISTICS

Truck			Shacman X9 4X2 Tipper Light Truck
Model			SX3163E2Y13B3620
Basic Configuration	Driving Type		4×4
	GVW		≤ 16T
	Cabin（mm）		X9/1995
	Engine	Model	YC4D130-33
		Engine Power	130
		Emissions	Euro Ⅱ
	Wheelbases（mm）		3600
	Chassis（mm）		800×250/7+4/double
	Gearbox		8JS85E-C+PTO
	Front Axle		2.5T/6.83
	Rear Axle		10T/6.83
	Leaf Spring		9/11+8
	Cargo Body Dimensions（mm）		3700-4000×2300×800
	Tyres		9.00R20
	Oil Tank		130L Iron
Functional Configuration	Power Steering		●
	Clutch Booster		●
	Electric Power Windows and Doors + Central Lock		●
	Remote Control Key		●
	Air Conditioner		●
	ABS		●
	Multimedia		○
	Metallic Paint		○
			●Standard Configuration○Optional/No such Configuration
