The Shacman F3000 4×2 Tractor Truck is a popular heavy-duty vehicle known for its reliability, power, and comfort. It’s a versatile model suitable for various transportation tasks, from hauling containers to transporting construction machinery. The F3000 series incorporates technology from MAN, offering a comfortable and powerful driving experience.
● The cab adopts European frame structure and has passed the most rigorous ECE-R29 crash test.
● Optimized shift operation: telescopic shaft shift operation can absorb vibration from the chassis, ensuring no spontaneous out of gear and control performance, improve the seal performance of the cab.
● Weichai Four-valve engine: strong power with large output torque, lower engine speed at maximum torque, which is the best power and explosive force in the industry.
● Fast transmission has dual intermediate shafts with high reliability; large speed ratio range, strong climbing ability, suitable for different working conditions; small speed ratio differential and high fuel economy.
| Shacman F3000 4×2 380hp Tractor Truck | ||
| Model | SX4185JT361 | |
| Max. running speed (km/h) | 100 | |
| Drive System | 4×2 | |
| Overall Dimensions （L*W*H）(mm) | 6150×2490×3710 | |
| Approach / departure angle (°) | 20 / 60 | |
| Curb weight (kg) | 7500 | |
| Engine | WP10.380E22 ( WEICHAI Engine, Euro 2) | |
| Horsepower | 380 hp | |
| Gearbox | 12JSD200T-B (FAST GEAR), manual, 12F & 2R | |
| Clutch | Ф 430 Diaphragm type | |
| Steering | ZF technology | |
| Cab | F3000 cabin with A/C & Double sleepers | |
| Axle | Front axle | MAN 7.5T |
| Rear axle | 13 Ton MAN driving axle , final ratio 4.266 | |
| Fifth wheel | 90# | |
| Tyre | 12.00R20 or 12R22.5 | |
| Oil tank(L) | 400L (ALLOY) | |
| Brakes | WABCO + ABS | |
| Parking brake (emergency brake): spring energy on rear alxes | ||
| Service brake: dual circuit compressed air brake | ||
| Optional | Cummins engine | |
| Hydraulic retarder | ||
| 1000 L fuel tank | ||
| JACOB Brake | ||
